An elementary treatise on mechanics, embracing the theory of statics and dynamics, and its applications to solids and fluids (1849)
Smith, Augustus William, 1802-1866 · New York, Harper · leaf 128
z.ADE = ft /= the length of thebeam, g the center ofgravity, and Dg=a. The wedge is kept in equilibrium by the pressure of thebeam upon it at E, and the horizontal force P acting upon itat some point H. The beam is kept in equilibrium by itsweight w acting at g and the reaction R of the face of… … R: a cos. j3 /cos. (a—0)But the principles of the wedge giveP=R. sin. a. THE SCREW. 105 _> a sin. a cos. (3 .. P=w.7. —. / cos. (a—(3) By an examination of this value of P, it will be seen that the power necessary to keep the wedge from moving will diminish as the wedge advances beneath the…
Mechanics, Analytic
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
