Elementary treatise on physics, experimental and applied : for the use of colleges and schools (1906)
Ganot, A. (Adolphe), 1804-1887, Atkinson, Edmund, 1831-1901, Reinold, A. W. (Arnold William), 1843-1921 · New York : Wood · leaf 494
hafting, or working hydraulic pumps ; in this latter casethe pump is worked directly, the plunger-rod of the pump being connectedto the engine crosshead. In fig. 444, F is a governor which controls theadmission of steam to the engine slide valve, so maintaining a more or lessconstant speed though… … Fig. 443 -475] Distribution of Steam. Slide Valves A77 from the engine crank shaft. When the speed of the engine increasesbeyond a certain limit, at which the governor is set, the arms fly outwards,lifting a lever against the action of a spring, which lever partially closes athrottle valve, H, in…
