Elements of plane and solid free-hand geometrical drawing, with lettering; and some elements of geometrical ornamental design, including the principals of harmonic angular ratios, etc. In three parts ... for draughtsmen and artisans; and teachers and students of industrial and mechanical drawing (1878)

Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 194

An illustration from Elements of plane and solid free-hand geometrical drawing, with lettering; and some elements of geometrical ornamental design, including the principals of harmonic angular ratios, etc. In three parts ... for draughtsmen and artisans; and teachers and students of industrial and mechanical drawing, 1878, leaf 194
F&97. 132 FREE-HAND GEOMETRICAL DRAWING. measured on lines drawn from & fixed point. When this pointis nearer the fixed line than the fixed distance, one branch of … the curve will be looped. Thus E E is the fixed line, and Athe fixed point. Then dC = de/ ba = be, etc. GEOMETRIC SYMBOLISM. 133 106. Turning now from these curves to a complex educa-tional establishment, we find for its corresponding fixed ele-ments, 1°, a foundation course of study, alike for…

Geometrical drawing · Mechanical drawing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
