tud to receive a nut or other female screwed fixing. 1402. Bolt head for forked spanner, used for sunk or countersunk heads. 1403. Hexagon head, with solid washer or collar. 1404. T head bolt for T grooves in castings.1405 & 1406. Countersunk heads. 1407. Eye bolt, with flat sides and straight… … M 2 I 72 THE ENGINEERS SKETCHBOOK, 1416. Collar stud. 1417. Split spring head bolt. 1418. Hook bolt. 1419. Solid head and collar bolt, bed bolt. 1420 & 1421. Heads for bolts to slide and turn in T grooves of planingmachines, &c. 1422. Countersunk bed bolt. Boiler stay. 1423, 1424, &…
