The engineer's sketch-book of mechanical movements, devices, appliances, contrivances and details employed in the design and construction of machinery for every purpose; (1902)
Barber, Thomas Walter. [from old catalog] · New York, Spon & Chamberlain · leaf 51
EE2- … i 46 TEE ENGINEERS SKETCH-BOOK. 317. Covered, solid end for crank pins, with screw adjustments for brasses. 318. Common forked rod end, with cap. 319. Hook bolt attachment for gudgeon; sometimes useful where there is thrust only on the gudgeon. 320. Double connecting rod, in which the rods form…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.] (1902)](https://img.insideoutlibrary.com/img/200/ia-electricengineer04inte-436-202@270.webp)
