The engineer's sketch-book of mechanical movements, devices, appliances, contrivances and details employed in the design and construction of machinery for every purpose; (1902)

Barber, Thomas Walter. [from old catalog] · New York, Spon & Chamberlain · leaf 67

An illustration from The engineer's sketch-book of mechanical movements, devices, appliances, contrivances and details employed in the design and construction of machinery for every purpose;, 1902, leaf 67 — onnecting an oscillating lever by a sliding joint to any reciprocating j)art, snch as a steam hammer head, enginecrosshead, &c. Sue Nos. 893, 894. 425. Suspended treadle motion. 426. Eccentric and sliding bush motion for a double piston engine. 427. Rocking lever motion by gearing and a tied… … 4-21.I

Mechanical movements
