The essentials of gearing; a text book for students and for self-instruction, containing numerous problems and practical formulas (1911)
Anthony, Gardner C. (Gardner Chace), 1856- · Boston : D.C. Heath · leaf 132
Plate 9. One Pitch Involute Gear and Pinion, showing Interference. REFERENCES TO TEXT. Art. 42, Page 30. Art. 44, Page 33. 43, 32. 46, 35. Plate 9. … GEAR 30 TEETH 1 PITCH INVOLUTE GEAR & PINIONSHOWING INTERFERENCE Plate lo. Plate 10. One Pitch Involute Pinion and Rack, showing Interference. IlEFEKENCES TO TEXT. Art. 42, Page 30.43, 32 AuT. 44, Puge 33.46, 35.Gearing
