er scale and completely dimen-sion. 163. Space 5V2 X V. Drawtwo views of the lever shown inFig. 416. Both views are to showthe true size of the lever. 164. Make detail drawings ofeach part of the screw stuffing boxof Fig. 417. Note that dottedsectioning is used here to indicate the separate pieces.… … £ /Yo/es r/g, ^06 164 ESSENTIALS OF DRAFTING FS^ \»9/
