u-ous; thus several sec-tions may be used andthe views representedas though occurring ona single plane. This isillustrated in Fig. 175,where the cuttingplane is changed asshown in the top view.Thus the front sec-tion is taken on theplane A, B, C, D, E,F, and the side sectionon a plane through…
