Estimates, costs and profits for house painting and interior decorating (1917)
Vanderwalker, Fred Norman, 1885- · Chicago, F.J. Drake & co · leaf 60
Figure 2.—Floor Plan. Scale: 1 inch=:4 feet, ^ incli=l foot.Walls : Outside, 1 foot thick. Inside, 6 inches. … Figure 3.—Side Elevation. Scale: 1 inch=4 feet. 58 ESTIMATES, COSTS AND PROFITS the rule and measure from the ridge poledown to the pencil line just made. Youwill find that it is just 2 inches. Accord-ing- to the scale on the plan then (1 in.equals 4 ft.) the height of gable is 2x4=8 ft. Now the…
Painting, Industrial
