Fifteen mechanical problems : reasons for their existence and their solution (1915)
Sargent, Charles Elliotte · leaf 165
ting the radiating surface of thebakery heating system it was estimated that all the steam used therein wouldflow through a half inch opening with but a few pounds drop in pressure. Duringthe night steam was cut off sufficiently long to tap a hole for a quarter inchcock ea3h side of the flanged… … 7i) half inch hole by the difference in pressure, and by checking the steam gages bytransposing them twice during the eight hour run, the proportion of steam usedby the bakery was ascertained, and the expense of the steam proportioned in asatisfactory manner. As many Chicago concerns were buying…
Mechanical engineering · Machine design · Theses
