), with a fillet (A) over it.Both the base and cap project i modulus from the side ofthe plinth. The plinth is 3| moduli in height. The Base of the Column. The base of the column must be placed over the cap ofthe pedestal and be of the same width as the plinth. Theheight of the base of the column… … PLATE III. THE TUSCAN CAPITAL AND ENTABLATURE. ViGNOLA gives the Tuscan capital a height of 1 modulusand a projection of 5 parts. The frieze of the capital has the same diameter as theupper part of the shaft of the column. The entablature — that is^ the architrave, frieze, and cor-nice — is 3|-…
