Vignola, 1507-1573, Juglaris, Tommaso, Locke, Warren S · [Boston, Press of Berwick & Smith] · leaf 47
f the first capital we have an ornamented bead.The convex moulding is also ornamented. The architravehas the same height and ^ modulus projection. It is dividedinto two bands, and is ornamented at the top by a filletwhich is -1- modulus high. The ornamentation of the metope only of the frieze… … PLATE X. SIMPLE DORIC INTERCOLUMNIATIOK From this arrangement are taken the measurements forall the modifications of the Doric Order. We divide the total height into 20 parts, one of whichserves us as the modulus, and which is also divided into 12parts. The base, with the fillet of the base of the…
