Buck, H. D. (Horace Davis) · New York, Bragdon, Lord & Nagle Company · leaf 136
will be noted in Fig. 90 that thereare two separate needle plates. The top one is for the needlesproper, while the lower one is for the auxiliary needles. These two plates are in perfect alignment, both as to thesurface and the needle tricks or slots. In the double jacquardthe front plate would be… … i Construction and Arrangement of Cams and Locks in Dubied Jacquard Machine. The Cam System Referring now to the cam system shown in Fig. 86, it willbe noted that while in general appearance the upper andlower set of locks are similar, the wing or stitch cam I and mare not only different in shape…
Machine knitting · Textile fabrics
