Free-hand drawing : a manual for teachers and students (1898)
Cross, Anson K. (Anson Kent), 1862-1944 · Boston : Ginn & Company · leaf 126
Fig. 46. A Serious Distortion of all at the Left of AB. … Fig. 47. A Satisfactory Representation. SCIENTIFIC PERSPECTIVE AND MODEL DRAWING. 109 three equal cylinders, A, B, and C, and traces upon a verticalpicture plane placed against the cylinders lines to cover eachcylinder and form the perspective of the cylinders; the cylindersmay roughly represent…
Drawing
Internet Archive · Boston Public Library · Public Domain Mark 1.0. Free to use for anything.
