Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1916)
Norton, Dora Miriam · Brooklyn : The author · leaf 149
Face view or fpame Section of fi?ameFig. 204 XVI. This method is given ia a slightly different form under Solutions of Problems, Chapter9 129 … FREEHAND PERSPECTIVE For the inner hexagon we may first study the actual shape inFig. 204, where it is seen that the vertical frame thickness canbe conveniently carried across to measure it at C^ on thenearest vertical, BC. We know this thickness to be one inch,which is more than one sixth and less…
Drawing · Perspective
