Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1910)
Norton, Dora Miriam · Brooklyn : D. M. Norton · leaf 82
h distances is simple and oftena convenience. Thus it is easy to see that in the diagram thevertical lines from 1, 2, 3, and 4 cut the diagonals proportionatelyto the divisions on GrH^ in this case into six equal parts. Thesedivisions can in turn be transferred to EF by horizontal linesfrom the… … Perspective representation or above.Fig. 103
Drawing
