The modern gas tractor, its construction, utility, operation and repair; a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction of all parts, their installation and adjustment as well as practical application of tractors in the field (1914)
Pagé, Victor Wilfred, 1885-1947 · New York : Norman W. Henley · leaf 247
r as pre-viously explained. The engine fly-wheel carries a clutchcasing in which a floating driving plate is keyed. Thisplate must turn with the fly-wheel but may move backand forth on its keys. The engine crank shaft termin-ates in the hub of the fly-wheel while the drive is takenup by an… … Clutch Shifting Rod Fig. 90.—Sectional View of Master Clutch Used on HoltTractors. the clutch case. The engine shaft and drive shaft areindependent when the clutch is disengaged. That is tosay, the drive shaft may remain stationary while the 252 The Modern Gas Tractor fly-wheel revolves. Attached…
Farm engines · Internal combustion engines
