The modern gas tractor, its construction, utility, operation and repair; a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction of all parts, their installation and adjustment as well as practical application of tractors in the field (1914)
Pagé, Victor Wilfred, 1885-1947 · New York : Norman W. Henley · leaf 311
SINGLE WHEELf0F? STEERING Fig. 134.—Front View of Three Wheel Hart-Parr Gas TractorFrame Utilizing One Wheel for Steering Purposes. knuckles to which the wheels are attached is clearlydepicted. In a number of cases the tractor frame issupported by three wheels, the member carried at The Modern Gas… … Fig. 135.—Sectional View of Front Wheel of Hart-Parr ThreeWheel Tractor Showiag Method of Supporting SteeringMember. the front end being utilized for steering. A frame ofthis pattern is shown at Fig. 134, the wheel beingop?rated through the usual form of steering wheelby means of reduction gearing…
Farm engines · Internal combustion engines
