Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 263

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 263
/HOLLOW DRAW IN 3PIN0LE/CONE / , BEARING … SPINDLE^^Sk- CLOSER SPRING CHUCK ADJUSTMENT FOR SPINDLE SECTION OF SPINDLE. 684. Plan. 685. Section of spindle. MOTION AND CONTROLLING DEVICES, ETC. 259

Mechanical movements
