Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 378

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 378
ed condition and the treatment of thedetails can be carried out in outline, as shown in Fig. 68.The drawing in this condition is ready to ink in for a pen-and-ink study, as in Fig. 69, to color in for a water-colorstudy, or to shade up in pencil for a finished pencil study,but in any drawing it is… … Fig. 70 of this architectural subject, but occasions may arise wherethese details are so large that it is desirable to work them ELEMENTARY PERSPECTIVE DRAWING 5 out with greater accuracy. In Fig. 70 is shown the Doriccapital and the method of getting its proper perspective.

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
