h goodcare, the life of these two materials is limited. One important feature of a good gutter is ARCHITECTURAL DRAFTING 271 to have the metal run \yell up under the roofingmaterial, and out over the crown-mould. Thiskeeps any water from overflowing up under theroof if the gutter becomes choked… … ^ -^-^AC FOATt Fig, 45b. Type of Open Cornice Known as Close-Eave Cornice. same material as the gutter. The shape of thedown-spouts may be either round or rectangu-lar; a verj^ common form is made of corrugatediron, either round or rectangular. The gutter,especially if a hanging gutter, must be…
