■ li-i … §7 ARCHITECTURAL DRAWING 79 to the front elevation and find at what point above the atticfloor headroom of about 6 6 can be obtained. This appliesto all attic rooms with the exception of the front room onthe right. The front and rear gables of the house formthe front and rear walls of the attic…
