Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 59

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 59
egiven point, and EOFis the given angle. With the vertex Oas a center, and any convenient radius, describe an arc EFcutting O E and O F in E and F. With P as a center, andthe same radius, describe an arc CD. With D as a center,and a radius equal to the chord of the arc EF, describe anarc cutting CD… … 44 §1 GEOMETRICAL DRAWING 45 Construction.—AB is the given side 3* long. WithA B &s 3i radius, and A and B as centers, describe two arcsintersecting in C. Draw CA and CB, and CA B is an equi-lateral triangle. Problem 9.—Tlie altitude of an equilateral trianglebeing given, to draw the triangle.…

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
