ch the air orproducts of combustion pass on their way to or fromthe furnace. Port-holes are situated directly abovethese regenerators which lead the gases through the 4—(1465) 50 GLASS floor or siege into the furnace chamber. The draughtis induced by a tall stack, which draws the gas fromthe gas… … Sectional Elevation.Fig. C SIEMENS SIEGBERT TYPE OF REGENERATIVEGLASS-MELTING FURNACE This gaseous mixture, whilst in combustion, is drawnacross the fm-nace chamber to the other end of thefurnace. The flames pla3ing across the tops of the potson either side pass do^vn through the port-holes…
