he treadles. The sketch represents two cams used in making plain cloth ; as one treadle is depressed by the extended portion of the cam, A, the other treadle is raised, and for the next pick the opposite takes place. That is, the harness that was first depressed is raised, and the one that was… … Fig. 54. Shedding Motion. nected with tlie treadle that is raised, and at the top it is attached to the lamb, ¥. This lamb is connected with the bottom of the harness, G, by means of a hook ; the top of the harness is connected by a similar hook to the top harness strap D.' This strap is fastened…
