The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ... (1851)

Byrne, Oliver · Philadelphia : H.C. Baird · leaf 189

An illustration from The practical metal-worker's assistant : containing the arts of working all metals and alloys, forging of iron and steel, hardening and tempering, melting and mixing, casting and founding, works in sheet metal, the processes dependent on the ductility of the metals, soldering, and the most improved processes, and tools employed by metal-workers, with the application of the art of electro-metallurgy to manufacturing processes : collected from original sources, and from the works of Holtzapffel, Bergeron, Leupold, Plumier, Napier, and others ..., 1851, leaf 189
rted or lowerpyramid b, and their vertical height in the sheet is equal to theslant height in the vessel; the superficies c, are those of a prism, 184 WORKS IN SHEET METAL, MADE BY JOINING. therefore they continue parallel, and have the vertical height of thepart c, of the figure; lastly, the sides… … 143. 145. 147. Should the vessels, instead of planes, have surfaces of single cur-vature, as in Figs. 144 and 146, the method is nearly as simple.The object is drawn on paper, and around its margin are markedseveral distances, either equal or unequal, and horizontal lines orordinates are drawn from…
