X 12 = 1200 X 338° =-405600 -^ 150000 = 2.7 inches. For example: find the lineal expansion ina wrought iron pipe 100 long, containingsteam at 338°. Expansion e(iuals 100x 12x 338°, divided by 150,000, equals 2.7. Special attention, then, must be given tothe expansion and contraction of pipes… … G.M.DAVIS REGULATOR CO. 422 MILWAUKEE AVE., CHICAGO Manufacturers of Steam Heating and Power Plant Specialties Pressure Regulators Balanced Valve Back Pressure Valve Float Valve Exhaust Jielief Valves Damper RegulatorSteam Trap Pump Governor Stop and Check Valves Water Relief ValveRadiator JUr…
