Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 22
piece determining thesize of the gage, while the jaws determine the size of the work. Wearis confined to the jaws and, after it occurs, the gage may be broughtback to its original size by removing the jaws and lapping them flat.Note that, if a limit gage is to be made, further division of… … easily be reduced by reversing the position of the hub as in Fig. 19,by Professor Sweet {Amer. Mack., Dec. 8, 1904). The improve-ment is obvious and it costs nothing. The Center of Pressure should be at the Center of a Bearing The neglect of this principle is almost universal and leads to…
Machine design
