Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 295

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 295
hment is being used the cross-feed screw is ren-dered inoperative by dropping the nut or removing the screw altogether.H is a knurled handwheel for operating adjusting screw G. 757. TAPER TURNING ATTACH-MENT. Bradford type. A taper slide madeadjustable for the required taper is fixed to aclamping…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
