Handbook for machine designers, shop men and draftsmen (1916)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York, McGraw-Hill book company, inc.; [etc., etc.] · leaf 453
o stop leakage around the rod.The bottom of the box should be flat—not beveled, as in Fig. 14. Areas of Ports and Pipes The areas of steam ports and pipes, as determined by an investigationof 165 single-cylinder engines ranging from 20 to 740 h.p. by Prof.John H. Bare {Trans. A. S. M. E., Vol. 18),… … Fig. 13.—Cylinder cover joint of the Straight-Line engine.
Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
