0 5 10 15 20 25 30 35° Fah. Difference in Temperature between Air Leaving and Water Entering Fig. io.—Relation of surface and capacity of intercoolers. … The Intercooler The design of intercoolers should be such that the air and waterpass through them in opposite directions in order that the incomingor coolest water may act on the air at the last stage of the cooling.The outer surface of the tubes should be the air surface as its greaterarea…
