Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 218
ELECTRICITY The machine is capable of feeding unbalanced loads withoutserious disturbance of the pressure on either side of the system. The principle of the Dobrowolski three wire dynamo is illustrated infig. 199. The armature A is tapped at two points, B and B, andconnected to slip rings C C. A… … Fig. 200.—Armature of Westinghouse three wire dynamo. Collector rings are mounted atone end of the armature as shown, and the leads to them with the armature winding aresimilar to those employed on the alternating current side of a rotary converter armature.The connections from the armature to…
Electrical engineering
Internet Archive · Brigham Young University · Public Domain Mark 1.0. Free to use for anything.
