Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 202
r and an auxiliaryset of collector rings. 1,460 //. 1 WKINS ELECTRIC IT Y Ques. In general, how does a rotary converter operate? Ans. On the collector ring side it operates as a synchronousmotor, while on the commutator side, as a dynamo. Its design in certain respects is a compromise between… … Fig. 2,035.—Diagram of two phase rotary converter. This is identical with the single phasemachine with the exception that another pair of collector rings are added, and connectedto points on the winding at right angles to the first, giving four blushes on the alternat-ing side for the two phase…
