Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 129
ttom portion of a slot, its otherside usually occupies the top portion of a slot distant from the first slotby the polar pitch. Bastard Winding*—In this type of winding, the end con-nectors project from the inductors in straight lines parallelto the shaft and then are bent inward, Jt has the… … Fig. 378.—Rear end of Westinghouse wave-barrel wound armature; view showing ventilation. winding at the commutator end. This class of winding is usedonly with bar armatures. Former Winding.—This relates to a method of windingcoils, and not to any particular type; that is, mechanical windingas…
Electrical engineering
Internet Archive · Brigham Young University · Public Domain Mark 1.0. Free to use for anything.
