Hicks' builders' guide : comprising an easy, practical system of estimating material and labor for carpenters, contractors and builders .. (1910)
Hicks, Isaac Perry, 1856- · New York : David Williams Company · leaf 104
DERS GUIDE. Fig. 69, A B is the run of the common rafter on theleft side of the hip, and the long run B E is the rise,A E being the length. A bevel set at E on the lineA E will give the plumb cut or down bevel, and atA the bottom bevel. B C is the run of the commonrafter on the right side of the… … B C Fig. 69.—Showing how several Diagrams may be combined to indi-cate directly from the Plan the different Lengths and Cuts ofall the Rafters. short run of the common rafter, A D the angle andrun of the hip, D F the rise of the hip and A F thelength of hip rafter. The bevel at F is the down…
