Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter (1887)

Wightwick, George · London, Lockwood · leaf 244

An illustration from Hints to young architects, comprising advice to those who, while yet at school, are destined to the profession, to such as, having passed their pupilage, are about to travel and to those who, having completed their education, are about to practise, together with a model specification involving a great variety of instructive and suggestive matter, 1887, leaf 244
DOOR ARCHITRAVE. Or 231 [put to windows of ... .moulded brick or terra-cottasills of the section in margin,also lintels as shown.] … No. 75. To put to the doorway of . . . .an architrave Architraves to of the best solid stone, moulded, and of doors. ^-j^Q scantling shown by fig. drawing No. The lintel to be of one stone; the jambs of one ) three > stone(s) down to plinth. [It is a fallacy or more j to imagine one stone…

Architecture
