Wright-Martin Aircraft Corporation, New Brunswick, N.J · New Brunswick, N.J., Wright-Martin Aircraft Corporation · leaf 83
rtS. £^»0 EXHAU5T CAM … Plate 28 Position of cams when piston is 32 m/m on 360 m/m disc or 10° past top firingcenter. 73 HISPANO— SUIZA always, in the direction it runs, by the club on thetiming disc. The engine being on top center on No. 1left continue to turn the engine until the disc is 32 m/mpast center or 10°, this…
Airplanes
