Leeds, Charles Carley, 1870- · New York, D. Van Nostrand company · leaf 16
inch radius, throw in the curvedlines representing the chamfer on the shank end. Observe how theradius center line is projected from the end view. FINISHED DRAWING.—In finishing the drawing, line inthe whole outline with care to give it a neat appearance, and to makeit clear and distinct, so that… … Center Lines CLASS Industrial trade t^achinist NAME John W.Roberts date Feb. I6-06. THE CARNEGIE TECHNICAL SCHOOLS P/TTSBUfiGH. PA. School of Apprentices and Journeymenmechanical dfawimg Flanged Pin SCALE full Size OWG.NO.C./000 LESSON No. 4. MACHINE BOLT.—Make a full-size three-view…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
