Hydraulic engineering; a practical treatise on the principles of water pressure and flow and their application to the development of water power, including the calculation, design and construction of water wheels, turbines, and other details of hydraulic power plants (1909)
American School (Chicago, Ill.), Black, Adolph, Turneaure, Frederick Eugene, 1866- · Chicago American School of Correspondence · leaf 175
rWheel or runner Guides … Fig-69. Fourneyron Turbine.Radial outward flow. motor is called an impulse turbine. If the wheel-passages are com-pletely filled by the water flowingthrough them under pressure, themotor is called a reaction turbine. The limit turbine is a type in-termediate between the impulseand the reaction…
