Hydraulic motors, with related subjects, including centrifugal pumps, pipes, and open channels, designed as a text-book for engineering schools (1905)
Church, Irving Porter, 1851-1931 · New York : J. Wiley & Sons; [etc, ] · leaf 120
vn, wx, wn, e, ci, cn, ph and pn, andit is evident that for a complete solution nine independentand simultaneous equations will be needed. For the presentall friction will be disregarded and the simple design already … Fig. 49. 98 HYDRAULIC MOTORS. § 65. shown in Figs. 45 to 49 inclusive will be the one treated. Wesuppose the cylindrical gate raised to its full height (full gate). The necessary equations are the following: From the parallelogram of velocities at entrance or point 1: Ci2=Wi2-\-vi2 — 2wiVi cos a…
Hydraulic machinery
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
