es; in which theabsolute path of a particle of water lies substantially in thesurface of a cylinder whose axis coincides with that of theturbine; that is, all points of this path are practically equidis-tant from the axis of rotation. (The Jonval Turbine.) IV. Mixed Type, or Mixed Flow.—In case the… … Fig. 57- 114 »§ 77. CLASSIFICATION OF TURBINES. 115 turbine is said to be one of Mixed Type. Most Americanturbines belong to this type of wheel. (Inward and down-ward discharge) 77. Radial, Inward-flow, Turbine. (The Francis Wheel.)—A simple arrangement of this type of turbine is shown in Fig. 57in…
