Industrial drawing and geometry; an introduction to various branches of technical drawing (1911)
Spooner, Henry John, 1856- · London, New York [etc.] Longmans, Green, and co. · leaf 156
Figs. 453, 454.—Dimensioned sketches of a cast-iron bracket. Pigs. 455, 456.—-Cast-iron foundation washer. … Pig. 457.—Engine fitters square. the bolts) over a large area. Draw the two views shown and add a section through the line AB, also a plan of the under side.Scale half size. Draw the circular view first. 137 138 INDUSTRIAL DRAWING AND GEOMETRY 240. A dimensioned sketch of an engine fitters square…
Mechanical drawing · Geometrical drawing
