Military sketching and map reading; including panoramic sketching and aerial photography (1921)
Grieves, Loren Chester, 1878- · Washington : United States Infantry Association · leaf 39
Fig. 8 in, or, better, stamped in with rubber stamps or steel type.Every feature is easily represented, and quickly indentedon the surface of the wax. When you have no further usefor a particular relief map, it may be torn up and another 86 Military Sketching and Map Reading one constructed from… … Fig. 9 Having done this work, it folloAvs automatically that he isable to read a military map. The following principles of contouring may be noted inconnection with Fig. 9: Relief INIaps 37 1. That all points on a contour line have the same ele-vation above the datum plane. 2. That, where the…
Maps, Military · Military sketching
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
