or the purpose of cutting strips of the samewidth with a smooth edge, and have proved very serviceable. Apair of bolometer strips is cut at one stroke from a double sheetof the platinum in silver foil. In this figure, c, is a clamp withscrews to secure the foil while cutting. The rest of the… … BOLOMETERFig. 10. To construct a bolometer in which the resistances of the stripsare equal within i per cent, to have the surfaces as nearly equalas possible, and, after this adjustment, to cover these stripselectrolytically with platinum black and then with soot is adifficult operation. In cases…
