gh B, pass along thethermometer valve spindle until they arrive at the fine plati-num wire which is shown at P. The head of the ther-mometer valve is connected to its spindle by the two ribs* Phil. Mag., 1895. f Proc. I.M.E., 1901. % Royal Soc. Paper, 1907. THERMODYNAMICS 79 which are made as thin… … Fig. 17.—Combined Admission and Thermometer Valve (Callendar). meter valve at the proper times is effected by suitable me-chanism. The thickness of the platinum wire was yxrooof an inch. At about 130 r.p.m. the lag of the thermometerwas not more than 10° of crank angle with a temperaturefluctuation…
