Self-propelled vehicles; a practical treatise on the theory, construction, operation, care and management of all forms of automobiles (1906)
Homans, James E. (James Edward), b. 1865 · New York, T. Audel & Company · leaf 613
valve; its outlet being controlled, as shown, by two hand-wheel valves—one leading to the main burner through the mix-ing tube, the other being intended to let out a sufficient supplyof gasoline to the starting device, which may be a detachabletorch, or auxiliary vaporizer, or some arrangement of… … Fig. 439.—Fuel Feed Regulator of a Steam Carriage Burner, intended forUse with Torch Burner Kindler or Auxiliary Vaporizer. A is the handwheel and needle valve regulating the feed to the main burner; B, thehand wheel and valve for operating the torch; C, the spring and headerattached to the main…
Automobiles
