The internal combustion engine; being a text book on gas, oil and petrol engines, for the use of students and engineers (1909)

Wimperis, Harry Egerton, 1876- · New York, Van Nostrand · leaf 271

An illustration from The internal combustion engine; being a text book on gas, oil and petrol engines, for the use of students and engineers, 1909, leaf 271 — usted. Fig. 83 showsa better and moref amiliar way of doingthe same thing. Airis sucked in past thejet F and out by theopening K. In rush-ing past the jet it SUcks Up a petrol Fia g3 _ Jet Carburettor and Float Chamber.Spray which evapor- A. Petrol inlet. B. needle valve. C. Floata tpcs sf<s it… … OIL AND PETROL ENGINES 251 left of the figure is seen what is called a float chamberfor keeping the petrol level constant. It operates muchas does a ball and cock feed to a water cistern. B is aneedle valve which gets pushed down on to its seatingby the levers D when the float C rises to the top.…

Internal combustion engines
