Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 110

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 110
alve for both cylinderswith direct steam passagesthrough the valve chamber.High pressure steam entersat the central port A. Steaminlet and exhaust indicated bythe arrows. Section V.STEAM APPLIANCES. Injectors, Steam Pumps, Condensers, Separators, Traps, and Valves. 372. PEERLESS IN-JECTOR.—An… … STCAM WATER
