Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 132
in the cross rail ofbracket 25. Near the base of this rod 44, a projecting stud 45 isadjusted at right angles and normally rests upon the right arm of thesimple lever 46, pivoted on the stud 47. A spiral spring 48 linkslever 46 to the bracket 49, and keeps the right arm of lever 46 inclose contact… … 128 JACQUARD MECHANISM AND HARNESS MOUNTING. Each vibratory movement of lever 51 recipro-cates the pawl catch 37, but since this is normallythe Mechanism. r Jl J clear of the ratchet wheel 36, through the energy in spiral spring 48 no rotation of the chain cylinder takes place.If, however, the left…
Textile machinery
